Eco Friendly Food Grade Paper Coating Machine

Overview

With a strong emphasis on sustainability, our machine uses eco-friendly coating materials that meet food safety regulations and standards. The food-grade coating provides a protective barrier on the paper surface, making it resistant to grease, oil, and moisture, ensuring the integrity of food items during storage and transportation.

The coating process is precisely controlled to ensure uniform coverage, resulting in high-quality food-grade paper suitable for a wide range of food packaging applications. Our machine is designed to be energy-efficient, minimizing resource consumption and waste generation, aligning with our commitment to environmental responsibility.

Eco Friendly Food Grade Paper Coating Machine

1. Drying system – 1 set

l Adopt oven for heating control.

l Each oven has three parts:

l Air blower -- provide air source for oven circulation.

l Hot air oven -- used for the preheating of circulating air source.The heating control of this part comes from the temperature controller located in the main operating panel.

l Infrared heat source - to provide a more direct, efficient radiation heat source.The working power is calculated and controlled according to man-machine exchange curve setting and machine speed.

l Two different heating parts of each oven are equipped with independent low-voltage control system.Users can turn off the heating function as needed and use it as an air cooling function.

l The overroller in the oven is provided with bearing.However, in order to reduce abrasion, there is an independent power system for the roller.Thus reducing the friction over the roller.

l The oven is equipped with waste air discharging system.For exhaust emissions.

l The outlet of the oven is equipped with an air cooling system to cool the surface of the material.

2.Out Feed Tension Control System

l The rear tension unit is made of alloy and cast iron

l Use the double side pressure rubber to cluth and feed and to guarantee the stale tension

l Web guide system before rewinder unit to error correct for long distance paper way.
